QUBIC SYSTEM – QS-220-PL Motion system

QS-220-PL Extended Set consists of four actuators, two power cabinets and one motion controller. The 3DOF configuration is dedicated to all racers who expect the most realistic and precise simulation. Incredible levels of vehicle feedback to the driver allow feeling exactly what the vehicle is doing in real-time. During the competition, drivers can feel every possible detail noticeable in a real race (including motor vibrations, road surface, bumps, shunting effects etc.) Due to the 3DOF set, you can feel like at a real racing session directly from your home.

QS-220-PL SET HIGHLIGHTS

Maximum velocity: 800 mm/s
Maximum acceleration: 0.8 G
Actuator stroke: 100 mm
Latency: <8 ms
Maximum control frequency: 1000 Hz
Vibration frequency range: 0-100 Hz

QS-220-PL SET KEY FEATURES

Proudly made in EU: Engineered, Designed and Manufactured in Poland
Super silent – extremely quiet operation
Used by professional race car drivers and pilots around the world
Top-quality ecosystem for personal and commercial applications
Supported by dedicated software QubicManager: motion adjustment, motion post-processing, extensive diagnostic or easy and fast use of predefined profiles
VR HeadWay technology support (VR sickness compensation)
Over 80+ integrated and supported racing and flight games
Compatible with professional simulation applications – Motion SDK (FSMI or FSDI) for software developers

Box 1. QS-220-PL motion set:
2x QS-L1 – linear actuator with cup holder
1x QS-SB2 – power cabinet (control module)
1x QS-SBML-2 – motion lock cable (up-link/down-link) – 2 m long
1x Power cable

Box 1. Dimensions
71 cm x 53 cm x 16 cm | 27.9 in x 20.9 in x 6.3 in

Box 1. Weight
30 kg| 66.14 lb

Box 2. QS-MC6 controller set:
1x QS-SBML-1 – motion lock with additional 2 m long cable
1x QS-MBT-1 – M-BUS terminator
1x USB cable – 0,5 m long cable (USB micro B)
1x CAT.5E patch cord cable – 2 m long

Box 2. Dimensions
20 cm x 20 cm x 13 cm | 7.9 in x 7.9 in x 5.1 in

Box 2. Weight
1 kg | 2.2 lb

GENERAL SPECIFICATION OF QS-220-PL SET

Architecture: 2 / 3 / 4 / 6 DOF (depending on user configuration and number of modules)
Actuator stroke: 100 mm | 3.93 in

Maximum velocity:
◦ Q-Mode (230V): 800 mm/s
◦ Performance Mode (115V/230V): 400 mm/s
◦ Heavy Duty Mode (115/230V): 300 mm/s

Maximum acceleration:
◦ Q-Mode (230V): 0.8G*
◦ Performance Mode (115V/230V): 0.7G*
◦ Heavy Duty Mode (115/230V): 0.4G*
*value of acceleration is limited for safety reasons

Recommended payload in 3DOF (2x QS-220-PL) configuration:
◦ Q-Mode: 200 kg
◦ Performance Mode: 250 kg
◦ Heavy Duty Mode: 350 kg

Vibrations frequency range: 0-100 Hz
Maximum control frequency: 1000 Hz
Latency: <8 ms

Product weight: 30 kg | 66 lb

MAIN DIMENSIONS
Total length: QS-L1: 90 mm | 3.55 in, QS-SB2: 385 mm | 15.16 in
Total width: QS-L1: 90 mm | 3.55 in, QS-SB2: 300 mm | 11.81 in
Total height: QS-L1: 553-653 mm | 22-26 in, QS-SB2: 88 mm | 3.46 in
Cable length (QS-L1 actuator – QS-SB2 Power cabinet): 1150 mm | 45.2 in

POWER REQUIREMENTS
Power supply requirements: 115/230 VAC Single Phase
Average power consumption in 3DOF configuration:
◦ Q-Mode: 260W (230V)
◦ Performance Mode: 280W (230V), 270W (115V)
◦ Heavy Duty Mode: 436W (230V), 462W (115V)

Peak current for breaker specification in 3DOF configuration:
◦ Q-Mode: 5.17A (230V)
◦ Performance Mode: 4.55A (230V), 7.35A (115V)
◦ Heavy Duty Mode: 5.88A (230V), 9.89A (115V)

Connection: USB

PRODUCT CARD

Even most advanced hardware is nothing without good software. QubicManager powered by Motion Systems company is professional and specialized software for the platform and is click and play compatible with all major racing and flight titles on PC and constantly updated to support new applications as they are released. Gives user possibilities of motion adjustment, motion post-processing, extensive diagnostic or easy and fast use of predefined profiles.

Over 80 integrated and supported racing and flight games.
